SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
15 Front wheel sensor (open
or short circuit)
Open or short circuit is de-
tected in the front wheel
sensor.
• Defective coupler be-
tween the front wheel
sensor and the hydraulic
unit assembly
• Open or short circuit in
the wire harness be-
tween the front wheel
sensor and the hydraulic
unit assembly
• Defective front wheel
sensor or hydraulic unit
assembly
16 Rear wheel sensor (open
or short circuit)
Open or short circuit is de-
tected in the rear wheel
sensor.
• Defective coupler be-
tween the rear wheel
sensor and the hydraulic
unit assembly
• Open or short circuit in
the wire harness be-
tween the rear wheel
sensor and the hydraulic
unit assembly
• Defective rear wheel
sensor or hydraulic unit
assembly
17*
45*
Front wheel sensor (miss-
ing pulses)
Front wheel sensor signal
is not received properly.
(Missing pulses are de-
tected in the signal while
the vehicle is traveling.)
• Foreign material ad-
hered around the front
wheel sensor
• Incorrect installation of
the front wheel
• Defective sensor rotor or
incorrect installation of
the rotor
• Defective front wheel
sensor or incorrect in-
stallation of the sensor
18*
46*
Rear wheel sensor (miss-
ing pulses)
Rear wheel sensor signal
is not received properly.
(Missing pulses are de-
tected in the signal while
the vehicle is traveling.)
• Foreign material ad-
hered around the rear
wheel sensor
• Incorrect installation of
the rear wheel
• Defective sensor rotor or
incorrect installation of
the rotor
• Defective rear wheel
sensor or incorrect in-
stallation of the sensor
21 Hydraulic unit assembly
(defective solenoid drive
circuit)
Solenoid drive circuit in
the hydraulic unit assem-
bly is open or short-circuit-
ed.
• Defective hydraulic unit
assembly
DTC Item Symptom Check point
