9-105
P0335
• Short circuit check
Disconnect the ECU related connectors before checking.
Refer to “PARTS CONNECTED TO THE ECU” on page 9-3.
Ground short circuit check “A”
Lines short circuit check “B”
B/Y
L
Y/G
P
Lg/L
O/WW/G
Y/L
Lg/W
B/L
Br/W
Gy/G
G/L
R/G
Lg/L
W/G
W/Y
G/R
Lg/B
L/W
Lg
B/Y
L
Y/G
P
W/G
Y/L
Lg/W
B/L
Br/W
Gy/G
Lg/L
W/G
W/Y
G/RL/W
Lg
B/Y B/L
2
*
2
**
1
*. XP560D
**. XP560E
Is resistance 0 ?
YES
Go to “Short circuit check”.
NO
a. Replace the wire harness.
b. Crank the engine, and then check the condition of the DTC using the malfunction mode of the
YDT.
Is it in the “Recovered” condition?
YES
Go to step 7, and complete the service.
NO
Go to “Short circuit check”.
Between crankshaft position sensor coupler “1”
and ground
black/yellow–ground
black/blue–ground
Crankshaft position sensor coupler “1”
black/yellow–any other coupler terminal
black/blue–any other coupler terminal
ECU coupler “2”
black/yellow–any other coupler terminal
black/blue–any other coupler terminal
To Next Page
