9-121
P0560, P0563
EAS20434
P0560, P0563
EAS33138
TROUBLESHOOTING
Item
• [P0560] Charging voltage is abnormal.
• [P0563] Vehicle system power voltage out of range
Fail-safe system
• Able to start engine
• Able to drive vehicle
Procedure
If more than one DTC is detected at the same time, perform troubleshooting of DTC listed below first.
• P0335
1. Malfunction in charging system.
• Check the charging system.
Refer to “CHARGING SYSTEM” on page 8-17.
2. Delete the DTC and check that the MIL goes off.
• Confirm that the DTC has a condition of “Recovered” using the YDT, and then delete the DTC.
Is check result OK?
YES
Repeat step 1.
NO
a. Defective rectifier/regulator or AC magneto Replace.
b. Defective connection in the charging system circuit Properly connect or replace the wire har-
ness.
c. Start the engine and let it idle for approximately 5 seconds.
d. Check the condition of the DTC using the malfunction mode of the YDT.
Is it in the “Recovered” condition?
YES
Go to step 2, and complete the service.
NO
Repeat step 1.
To Next Page
