9-150
P1601
• Short circuit check
Disconnect the ECU related connectors before checking.
Refer to “PARTS CONNECTED TO THE ECU” on page 9-3.
Ground short circuit check “A”
Lines short circuit check “B”
Between sidestand relay coupler “1” and ground light green–ground
Between sidestand switch coupler “3” and
ground
light green–ground
Sidestand relay coupler “1” light green–any other coupler terminal
ECU coupler “2” light green–any other coupler terminal
Sidestand switch coupler “3” light green–any other coupler terminal
B/Y
L
Y/G
P
Lg/L
O/WW/G
Y/L
Lg/W
B/L
Br/W
Gy/G
G/L
R/G
Lg/L
W/G
W/Y
G/R
Lg/B
L/W
Lg
B/Y
L
Y/G
P
W/G
Y/L
Lg/W
B/L
Br/W
Gy/G
Lg/L
W/G
W/Y
G/RL/W
Lg
Lg
B
G/R
G/Y
L/Y
Lg
Lg
B
G/R
G/Y
L/Y
Lg
BA
2
*
1
3
1
3
2
**
*. XP560D
**. XP560E
Is resistance ?
YES
Go to step 5.
NO
a. Replace the wire harness.
b. Push the ON/start switch, and then extend and retract the sidestand.
c. Check the condition of the DTC using the malfunction mode of the YDT.
Is it in the “Recovered” condition?
YES
Go to step 7, and complete the service.
NO
Go to step 5.
To Next Page
