9-178
18, 46_ABS
EAS20709
18, 46_ABS
EAS33373
TROUBLESHOOTING
Item
Rear wheel sensor (missing pulses)
Procedure
TIP
If pulse gaps are detected when the vehicle is traveling at a speed of 30 km/h (19 mi/h) or more, DTC
No. 18 will be recorded. If the vehicle is traveling at a speed of 29 km/h (18 mi/h) or less, DTC No. 46
will be recorded first and DTC No. 18 will be recorded if the condition continues.
1. Foreign material adhered around the rear wheel sensor
• Check the surface of the sensor rotor and wheel sensor for foreign material, such as metal particles.
2. Incorrect installation of the rear wheel
• Check the components for looseness, distortion, and bends.
Refer to “CHECKING THE REAR WHEEL” on page 4-33.
3. Defective sensor rotor or incorrect installation of the rotor
• Check the surface of the sensor rotor for damage.
Refer to “MAINTENANCE OF THE REAR WHEEL SENSOR AND SENSOR ROTOR” on page 4-
34.
4. Defective rear wheel sensor or incorrect installation of the sensor
• Check the wheel sensor for damage and the installed condition of the sensor.
Refer to “MAINTENANCE OF THE REAR WHEEL SENSOR AND SENSOR ROTOR” on page 4-
34.
Is check result OK?
YES
 Go to step 2.
NO
 Clean the sensor rotor and wheel sensor.
Is check result OK?
YES
 Go to step 3.
NO
 Replace the wheel axle, tire, rear wheel, wheel bearings or oil seals.
Is check result OK?
YES
 Go to step 4.
NO
 Replace the sensor rotor.
Is check result OK?
YES
 Replace the hydraulic unit assembly (ABS ECU).
NO
 Repair or replace the wheel sensor.
