YASKAWA AC Drive-A1000 User Manual

Predefined V/f Patterns for Models CIMR-Ao5A0011 to 0032
Table 5.26 Rated Torque Characteristics, Settings 0 to 3
Setting = 0 50 Hz Setting = 1 60 Hz Setting = 2 60 Hz Setting = 3 72 Hz
0
20.1
575
1.3 2.5 50
40.3
Voltage (V)
Frequency (Hz)
0
20.1
40.3
575
1.5 3 60
Voltage (V)
Frequency (Hz)
Voltage (V)
Frequency (Hz)
0
20.1
40.3
575
1.5 3 6050
0
20.1
40.3
575
1.5 3 7260
Voltage (V)
Frequency (Hz)
Table 5.27 Derated Torque Characteristics, Settings 4 to 7
Setting = 4 50 Hz Setting = 5 50 Hz Setting = 6 60 Hz Setting = 7 60 Hz
Voltage (V)
Frequency (Hz)
0
17.3
575
1.3 25 50
100.6
0
20.1
575
1.3 25 50
143.8
Voltage (V)
Frequency (Hz)
Voltage (V)
Frequency (Hz)
0
17.3
575
1.5 30 60
100.6
0
20.1
575
1.5 30 60
143.8
Voltage (V)
Frequency (Hz)
Table 5.28 High Starting Torque, Settings 8 to B
Setting = 8 50 Hz Setting = 9 50 Hz Setting = A 60 Hz Setting = B 60 Hz
0
25.9
575
1.3 2.5 50
51.8
Voltage (V)
Frequency (Hz)
Voltage (V)
Frequency (Hz)
0
31.6
575
1.3 2.5 50
66.1
Voltage (V)
Frequency (Hz)
0
25.9
575
1.5 3 60
51.8
0
37.4
575
1.5 3 60
66.1
Voltage (V)
Frequency (Hz)
Table 5.29 Constant Output, Settings C to F
Setting = C 90 Hz Setting = D 120 Hz Setting = E 180 Hz Setting = F 60 Hz
0
20.1
40.3
575
1.5 3 9060
Voltage (V)
Frequency (Hz)
0
20.1
40.3
575
1.5 3 12060
Voltage (V)
Frequency (Hz)
0
20.1
40.3
575
1.5 3 18060
Voltage (V)
Frequency (Hz)
Voltage (V)
Frequency (Hz)
0
20.1
40.3
575
1.5 3 60
Setting a Custom V/f Pattern (Setting F: Default)
Set parameter E1-03 to F to create a custom V/f pattern by setting parameters E1-04 to E1-13.
When initialized, the default values for parameters E1-04 to E1-13 will be equal to V/f pattern 1 of the predefined patterns.
n
V/f Pattern Settings E1-04 to E1-13
If E1-03 is set to a preset V/f pattern (i.e., a value other than F), the user can monitor the V/f pattern in parameters E1-04
through E1-13. To create a new V/f pattern, set E1-03 to F. Refer to V/f Pattern on page 187 for an example custom V/f
pattern.
Note:
Certain E1-oo parameters might not be visible depending on the control mode. Refer to Parameter List on page 379 for details.
No. Parameter Name Setting Range Default
E1-04 Maximum Output Frequency 40.0 to 400.0 Hz
<1> <2>
E1-05 Maximum Voltage 0.0 to 733.1 V
<1>
E1-06 Base Frequency 0.0 to [E1-04]
<1> <2>
E1-07 Middle Output Frequency 0.0 to [E1-04]
<1>
5.5 E: Motor Parameters
186
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
