YASKAWA AC Drive-A1000 User Manual

No.
(Addr.
Hex)
Name Description Values Page
n3-03
(58A)
High-Slip Braking Dwell
Time at Stop
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG
Sets the time the drive will run with minimum frequency (E1-09) at the end
of deceleration.
If this time is set too low, the machine inertia can cause the motor to rotate
slightly after HSB.
Default: 1.0 s
Min.: 0.0
Max.: 10.0
271
n3-04
(58B)
High-Slip Braking Overload
Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG
Sets the time required for an HSB overload fault (oL7) to occur when the drive
output frequency does not change during an HSB stop. This parameter does
not typically require adjustment.
Default: 40 s
Min.: 30
Max.: 1200
271
n3-13
(531)
Overexcitation Deceleration
Gain
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the gain applied to the V/f pattern during Overexcitation Deceleration
(L3-04 = 4).
Default: 1.10
Min.: 1.00
Max.: 1.40
271
n3-14
(532)
High Frequency Injection
during Overexcitation
Deceleration
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
272
n3-21
(579)
High-Slip Suppression
Current Level
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets output current level at which the drive will start reducing the
overexcitation gain in order to prevent a too high motor slip during
Overexcitation Deceleration. Set as a percentage of the drive rated current.
Default: 100%
Min.: 0
Max.: 150
272
n3-23
(57B)
Overexcitation Operation
Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
0: Enabled in both directions
1: Enabled only when rotating forward
2: Enabled only when in reverse
Default: 0
Range: 0 to 2
272
<1> Default setting is dependent on parameters C6-01, Drive Duty Selection, and L8-38, Frequency Reduction Selection.
u
n5: Feed Forward Control
OLV/PMOLV/PM AOLV/PMAOLV/PM CLV/PMCLV/PM
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
No.
(Addr.
Hex)
Name Description Values Page
n5-01
(5B0)
Feed Forward Control
Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM CLV/PM
CLV
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
273
n5-02
(5B1)
Motor Acceleration Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM CLV/PM
CLV
Sets the time required to accelerate the motor at the rated torque from stop to
rated speed.
Default:
<1> <2>
Min.: 0.001 s
Max.: 10.000 s
273
n5-03
(5B2)
Feed Forward Control Gain
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM CLV/PM
CLV
Sets the ratio between motor and load inertia. Lower this setting if overshoot
occurs at the end of acceleration.
Default: 1.00
Min.: 0.00
Max.: 100.00
274
<1> Default setting is dependent on parameter E5-01, Motor Code Selection.
<2> Default setting is dependent on parameters C6-01, Drive Duty Selection, and o2-04, Drive Model Selection.
B.11 n: Special Adjustment
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
437
B
Parameter List
