C.2 Communication Specifications

MEMOBUS/Modbus specifications appear in the following table:

Item Specifications

Interface RS-422, RS-485

Communications Cycle Asynchronous (Start-stop synchronization)

Communication

Parameters

Communication Speeds

Available

1.2; 2.4; 4.8; 9.6; 19.2; 38.4; 57.6; 76.8; 115.2 kbps

Data length 8 bit (fixed)

Parity Select even, odd, or none

Stop bit 1 bit (fixed)

Protocol MEMOBUS/Modbus (using RTU mode only)

Max Number of Slaves 255 drives

C.2 Communication Specifications

YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual

465
