8.2 Drive Options and Peripheral Devices
The following table of peripheral devices lists the names of the various accessories and options available for Yaskawa drives.
Contact Yaskawa or your Yaskawa agent to order these peripheral devices.
• Peripheral Device Selection: Refer to the Yaskawa catalog for selection and part numbers.
• Peripheral Device Installation: Refer to the corresponding option manual for installation instructions.
Table 8.1 Available Peripheral Devices
Option Model Number Description
Power Options
DC Reactor — Improves the power factor by suppressing harmonic distortion from the power supply.
AC Reactor —
Protects the drive when operating from a large power supply and improves the power
factor by suppressing harmonic distortion. Highly recommended for power supplies that
exceed 600 kVA.
Braking Resistor ERF-150WJ Series
For use with systems that require dynamic braking with up to 3% ED. If higher ED is
required, use a Braking Resistor Unit.
Input/Output Option Cards
Analog Input AI-A3
Allows high precision, high resolution analog reference input
Input channels: 3
Voltage input: -10 to 10 Vdc (20 kΩ), 13 bit signed
Current input: 4 to 20 mA or 0 to 20 mA (250 kΩ), 12 bit
Analog Monitor AO-A3
Provides extra multi-function analog output terminals
Output channels: 2
Output voltage: -10 to 10 V, 11 bit (signed)
Digital Input DI-A3
Sets the frequency reference by digital inputs
Input channels: 18 (including SET signal and SIGN signal)
Input signal type: BCD 16 bit (4 digit), 12 bit (3 digit), 8 bit (2 digit)
Input signal: 24 Vdc, 8 mA
Digital Output DO-A3
Provides extra insulated multi-function digital outputs
Photocoupler relays: 6 (48 V, up to 50 mA)
Contact relays: 2 (250 Vac/up to 1 A, 30 Vdc/up to 1 A)
Motor Speed Feedback Option Cards
Complementary PG PG-B3
For speed feedback input by connecting a motor encoder
Input: 3-track (can be used with 1 or 2 tracks), HTL encoder connection, 50 kHz max
Output: 3-track, open collector
Encoder power supply: 12 V, max current 200 mA
Line Driver PG PG-X3
For speed feedback input by connecting a motor encoder
Input: 3-track (can be used with 1 or 2 tracks), line driver, 300 kHz max
Output: 3-track, line driver
Encoder power supply: 5 V or 12 V, max current 200 mA
Communication Option Cards
PROFIBUS-DP SI-P3 Connects to a PROFIBUS-DP network.
CC-Link SI-C3 Connects to a CC-Link network
DeviceNet SI-N3 Connects to a DeviceNet network
CANopen SI-S3 Connects to a CANopen network.
MECHATROLINK-II SI-T3 Connects to a MECHATROLINK-II network.
Interface Options
LED Operator JVOP-182 5-digit LED operator; max. cable length for remote usage: 3 m
Remote Operator Cable WV001/WV003
RJ-45, 8-pin straight through, UTP CAT5e, extension cable (1 m or 3 m) to connect the
digital operator for remote operation.
USB Copy Unit JVOP-181
Allows the user to copy and verify parameter settings between drives.
Also functions as an adapter to connect the drive to a USB port on a PC.
Mechanical Options
Attachment for External
Heatsink
EZZ020786
Installation kit for mounting the drive with the heatsink outside of the panel (Side-by-
Side mounting possible)
Installation Support Set A EZZ020642A
For installing the digital operator keypad on the outside of an enclosure panel that houses
the drive. Refer to Digital Operator Remote Installation on page 43.
Installation Support Set B EZZ020642B
Others
24 V Power Supply PS-A10L, PS-A10H Supplies the drive controller with 24 Vdc power during main power loss
8.2 Drive Options and Peripheral Devices
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
361
8
Peripheral Devices &
Options
