B.1 Understanding Parameter Descriptions
u
Control Modes, Symbols, and Terms
The table below lists terms and symbols used in this section to indicate which parameters are available in which control modes.
Note: Refer to Control Mode Selection on page 30 for detailed instructions on each control mode.
Table B.1 Symbols and Icons Used in Parameter Descriptions
Symbol Description
All Modes
Parameter is available in all control modes.
V/fV/f
Parameter is available when operating the drive with V/f Control.
V/f w PGV/f w PG
Parameter is available when operating the drive with V/f with PG Control.
OLVOLVOLVOLV
Parameter is available when operating the drive with Open Loop Vector.
CLVCLV
Parameter is available when operating the drive with Closed Loop Vector.
OLV/PMOLV/PM
Parameter is available when operating the drive with Open Loop Vector for PM motors.
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
AOLV/PMAOLV/PM
Parameter is available when operating the drive with Advanced Open Loop Vector for PM motors.
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
CLV/PMCLV/PM
Parameter is available when operating the drive with Closed Loop Vector for PM motors.
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Parameter can be changed during run.
Motor 2
Refers to a second motor when the drive is operating two motors. Switch between these motors using the multi-
function input terminals.
Note: If a parameter is not available in a certain control mode, the symbol for that control mode appears white with a gray outline.
B.1 Understanding Parameter Descriptions
380
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
