H3 Multi-Function Analog Input Settings
H3-oo
Setting
Function Description Page
10 Forward torque limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLV
10 V = Motor rated torque
233
11 Reverse torque limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLV
10 V = Motor rated torque
233
12 Regenerative torque limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLV
10 V = Motor rated torque
233
13 Torque reference/Torque limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLV
10 V = Motor rated torque
233
14 Torque compensation
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLV
10 V = Motor rated torque
233
15 General torque limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
AOLV/PM
OLV
CLV/PM
CLV
10 V = Motor rated torque
233
16 Differential PID feedback
All Modes
10 V = 100%
233
1F Through mode
All Modes
Set this value when using the terminal in the pass-through mode.
233
30 to 32
DriveWorksEZ
analog input 1 to 3
All Modes
Output is determined by the function selected using DWEZ.
233
u
H4: Analog Outputs
No.
(Addr.
Hex)
Name Description Values Page
H4-01
(41D)
Multi-Function Analog
Output Terminal FM
Monitor Selection
All Modes
Selects the data to be output through multi-function analog output terminal
FM.
Set the desired monitor parameter to the digits available in Uo-oo.
For example, enter “103” for U1-03.
Default: 102
Range: 000 to 999
234
H4-02
(41E)
Multi-Function Analog
Output Terminal FM Gain
All Modes
Sets the signal level at terminal FM that is equal to 100% of the selected
monitor value.
Default: 100.0%
Min.: -999.9
Max.: 999.9
234
H4-03
(41F)
Multi-Function Analog
Output Terminal FM Bias
All Modes
Sets the signal level at terminal FM that is equal to 0% of the selected monitor
value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
234
H4-04
(420)
Multi-Function Analog
Output Terminal AM
Monitor Selection
All Modes
Selects the data to be output through multi-function analog output terminal
AM.
Set the desired monitor parameter to the digits available in Uo-oo.
For example, enter “103” for U1-03.
Default: 103
Range: 000 to 999
234
H4-05
(421)
Multi-Function Analog
Output Terminal AM Gain
All Modes
Sets the signal level at terminal AM that is equal to 100% of the selected
monitor value.
Default: 50.0%
Min.: -999.9
Max.: 999.9
234
H4-06
(422)
Multi-Function Analog
Output Terminal AM Bias
All Modes
Sets the signal level at terminal AM that is equal to 0% of the selected monitor
value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
234
B.9 H Parameters: Multi-Function Terminals
424
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
