H2: Multi-Function Digital Outputs
No.
(Addr.
Hex)
Name Description Values Page
H2-01
(40B)
Terminal M1-M2 function
selection (relay)
All Modes
Refer to H2 Multi-Function Digital Output Settings on pages 419 to 422 for
descriptions of setting values.
Default: 0
Range: 0 to 192
218
H2-02
(40C)
Terminal M3-M4 function
selection (relay)
Default: 1
Range: 0 to 192
218
H2-03
(40D)
Terminal M5-M6 function
selection (relay)
Default: 2
Range: 0 to 192
218
H2-06
(437)
Watt Hour Output Unit
Selection
All Modes
Outputs a 200 ms pulse signal when the watt-hour counter increases by the
units selected.
0: 0.1 kWh units
1: 1 kWh units
2: 10 kWh units
3: 100 kWh units
4: 1000 kWh units
Default: 0
Range: 0 to 4
227
OLV/PMOLV/PM AOLV/PMAOLV/PM CLV/PMCLV/PM
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
H2 Multi-Function Digital Output Settings
H2-oo
Setting
Function Description Page
0 During run
All Modes
Closed: A Run command is active or voltage is output.
219
1 Zero speed
All Modes
Open: Output frequency is above the minimum output frequency set in E1-09.
Closed: Output frequency is below the minimum output frequency set in E1-09.
219
2 Speed agree 1
All Modes
Closed: Output frequency equals the speed reference (plus or minus the hysteresis set to L4-02).
219
3 User-set speed agree 1
All Modes
Closed: Output frequency and speed reference equal L4-01 (plus or minus the hysteresis set to
L4-02).
220
4 Frequency detection 1
All Modes
Closed: Output frequency is less than or equal to the value in L4-01 with hysteresis determined
by L4-02.
220
5 Frequency detection 2
All Modes
Closed: Output frequency is greater than or equal to the value in L4-01 with hysteresis determined
by L4-02.
221
6 Drive ready
All Modes
Closed: Power up is complete and the drive is ready to accept a Run command.
221
7 DC bus undervoltage
All Modes
Closed: DC bus voltage is below the Uv trip level set in L2-05.
221
8 During baseblock (N.O.)
All Modes
Closed: Drive has entered the baseblock state (no output voltage).
222
9 Frequency reference source
All Modes
Open: External Reference 1 or 2 supplies the frequency reference (set in b1-01 or b1-15).
Closed: Digital operator supplies the frequency reference.
222
A Run command source
All Modes
Open: External Reference 1 or 2 supplies the Run command (set in b1-02 or b1-16).
Closed: Digital operator supplies the Run command.
222
B Torque detection 1 (N.O.)
All Modes
Closed: An overtorque or undertorque situation has been detected.
222
C Frequency reference loss
All Modes
Closed: Analog frequency reference has been lost.
222
B.9 H Parameters: Multi-Function Terminals
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
419
B
Parameter List
