6.8 Copy Function Related Displays
u
Tasks, Errors, and Troubleshooting
The table below lists the messages and errors that may appear when using the Copy function.
When executing the tasks offered by the Copy function, the operator will indicate the task being performed. When an error
occurs, a code appears on the operator to indicate the error. Note that errors related to the Copy function do not trigger a multi-
function output terminal that has been set up to close when a fault or alarm occurs. To clear an error, simply press any key on
the operator and the error display will disappear.
Table 6.18 lists the corrective action that can be taken when an error occurs.
Note: 1. Whenever using the copy function, the drive should be fully stopped.
2. The drive will not accept a Run command while the Copy function is being executed.
3. Parameters can only be saved to a drive when the voltage class, capacity, control mode, and software version match.
Table 6.18 Copy Function Task and Error Displays
Digital Operator Display Task
CoPy Writing Parameter Settings (flashing)
Cause Possible Solutions
Parameters are being written to the drive. Not an error.
Digital Operator Display Task
CPEr Control Mode Mismatch
Cause Possible Solutions
Control mode of the parameters to be loaded onto
the drive and the control mode already set to the
drive don’t match.
Check the control mode for the parameters that are to be loaded onto the drive and the control mode
set to the drive those parameters will be written to. Set the same control mode using parameter A1-02
and try again.
Digital Operator Display Task
CPyE Error Writing Data
Cause Possible Solutions
Failed writing parameters. Try writing parameters again.
Digital Operator Display Task
CSEr Copy Unit Error
Cause Possible Solutions
Hardware fault Replace the operator or the USB Copy Unit.
Digital Operator Display Task
dFPS Drive Model Mismatch
Cause Possible Solutions
The drive from which the parameter were copied
and the drive you are attempting to write to are not
the same model.
• The drive the parameters were copied from is a
different model drive.
• The drive you attempting to write to is a different
model.
Check the model number of the drive that the parameters were copied from and the model of the
drive you are attempting to write those parameters to.
Make sure the drive from which the parameter are copied and the drive to be written to have the same
model numbers and software versions.
Digital Operator Display Task
End Task Complete
Cause Possible Solutions
Finished reading, writing, or verifying parameters. Not an error.
Digital Operator Display Task
iFEr Communication Error
Cause Possible Solutions
A communication error occurred between the drive
and the operator or the USB copy unit.
Check the cable connection.
A non-compatible cable is being used to connect
the USB Copy Unit and the drive.
Use the cable originally packaged with the USB Copy Unit.
6.8 Copy Function Related Displays
332
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
