1.4 Drive Models and Enclosure Types
Two types of enclosures are offered for A1000 drives.
• IP00/Open-Chassis models are designed for installation in an enclosure panel that serves to protect personnel from injury
caused by accidentally touching live parts.
• IP20/NEMA Type 1 models mount to an indoor wall or in an enclosure panel.
Table 1.3 describes drive enclosures and models.
Table 1.3 Drive Models and Enclosure Types
Voltage Class
Enclosure Type
IP20/NEMA Type 1
<1>
CIMR-Ao
IP00/Open-Chassis
CIMR-Ao
Three-Phase
600 V Class
5A0003F
<1>
5A0004F
<1>
5A0006F
<1>
5A0009F
<1>
5A0011F
<1>
5A0017F
<1>
5A0022F
<1>
5A0027F
<1>
5A0032F
<1>
<1> Removing the top protective cover or bottom conduit bracket from an IP20/NEMA Type 1 drive voids NEMA Type 1 protection while maintaining
IP20 conformity.
