YASKAWA AC Drive-A1000 User Manual

CIMR - A U 5 A
0003 F
A A
Drive
A1000
Series
No.
Enclosure
Type
Design
Revision
Order
No.
Customized
Specifications
A Standard model
No.
Region
Code
U USA
IP00
F
NEMA
Type 1
A
No. Voltage Class
No.
Environmental
Specification <1>
A
M
N
Standard
Humidity- and
dust-resistant
Oil-resistant
3-phase, 500-600 Vac
5
n
Three-Phase 600 V
Normal Duty Heavy Duty
No.
Max. Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
0003 1.5 2.7 0003 0.75 1.7
0004 2.2 3.9 0004 1.5 3.5
0006 3.7 6.1 0006 2.2 4.1
0009 5.5 9 0009 3.7 6.3
0011 7.5 11 0011 5.5 9.8
0017 11 17 0017 7.5 12.5
0022 15 22 0022 11 17
0027 18.5 27 0027 15 22
0032 22 32 0032 18.5 27
<1> Drives with these specifications do not guarantee complete protection from the environmental conditions indicated.
Note: Refer to Drive Models and Enclosure Types on page 34 for differences regarding enclosure protection types and component descriptions.
