YASKAWA AC Drive-A1000 User Manual

1.2 General Description
u
A1000 Model Selection
Refer to Table 1.1 for drive selection depending on the motor power and Normal or Heavy Duty rating.
Note: The models and capacities in shown here are based on standard settings and operation conditions. Higher carrier frequencies and higher ambient
temperatures require derating.
Table 1.1 A1000 Models
Motor Power (kW)
Three-Phase 600 V Class
Heavy Duty Rating Normal Duty Rating
Model CIMR-Ao
Rated Output
Current (A)
<1>
Model CIMR-Ao
Rated Output
Current (A)
<2>
0.75 5A0003 1.7 – –
1.5 5A0004 3.5 5A0003 2.7
2.2 5A0006 4.1 5A0004 3.9
3.7 5A0009 6.3 5A0006 6.1
5.5 5A0011 9.8 5A0009 9
7.5 5A0017 12.5 5A0011 11
11 5A0022 17 5A0017 17
15 5A0027 22 5A0022 22
18.5 5A0032 27 5A0027 27
22 – – 5A0032 32
<1> These values assume the carrier frequency is not set higher than 8 kHz.
<2> These values assume the carrier frequency is set to 2 kHz.
Note: Current derating is required when setting the carrier frequency higher. Refer to Carrier Frequency Derating on page 377 for details.
1.2 General Description
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
29
1
Receiving
