YASKAWA AC Drive-A1000 - D7: Offset Frequency

No.
(Addr
Hex.)
Name Description Values Page
d6-03
(2A2)
Field Forcing Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVOLV CLV
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
183
d6-06
(2A5)
Field Forcing Limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVOLV CLV
Sets the upper limit of the excitation current command during magnetic field
forcing. A setting of 100% is equal to motor no-load current. Disabled only
during DC Injection Braking.
Default: 400%
Min.: 100
Max.: 400
183
u
d7: Offset Frequency
No.
(Addr.
Hex)
Name Description Setting Page
d7-01
(2B2)
Offset Frequency 1
All Modes
Added to the frequency reference when the digital input “Frequency offset 1”
(H1-oo = 44) is switched on.
Default: 0.0%
Min.: -100.0
Max.: 100.0
183
d7-02
(2B3)
Offset Frequency 2
All Modes
Added to the frequency reference when the digital input “Frequency offset 2”
(H1-oo = 45) is switched on.
Default: 0.0%
Min.: -100.0
Max.: 100.0
183
d7-03
(2B4H)
Offset Frequency 3
All Modes
Added to the frequency reference when the digital input “Frequency offset 3”
(H1-oo = 46) is switched on.
Default: 0.0%
Min.: -100.0
Max.: 100.0
183
B.6 d: References
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
401
B
Parameter List
