YASKAWA AC Drive-A1000 User Manual

u
E4: Motor 2 Parameters
These parameters are hidden when a PM motor control mode has been selected for motor 1 (A1-02 = 5, 6, 7).
No.
(Addr.
Hex)
Name Description Values Page
E4-01
(321)
Motor 2 Rated Current
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the full load current for motor 2. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 10% of drive
rated current
Max.: 200% of
drive rated current
<2>
191
E4-02
(322)
Motor 2 Rated Slip
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the rated slip for motor 2. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0.00 Hz
Max.: 20.00 Hz
<2>
191
E4-03
(323)
Motor 2 Rated No-Load
Current
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the no-load current for motor 2. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0 A
Max.: E4-01
<2>
191
E4-04
(324)
Motor 2 Motor Poles
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the number of poles of motor 2. Automatically set during Auto-Tuning.
Default: 4
Min.: 2
Max.: 48
192
E4-05
(325)
Motor 2 Line-to-Line
Resistance
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the phase-to-phase resistance for motor 2. Automatically set during
Auto-Tuning.
Default:
<1>
Min.: 0.000 Ω
Max.: 65.000 Ω
192
E4-06
(326)
Motor 2 Leakage Inductance
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the voltage drop for motor 2 due to motor leakage inductance as a
percentage of rated voltage. Automatically set during Auto-Tuning.
Default:
<1>
Min: 0.0%
Max: 40.0%
192
E4-07
(343)
Motor 2 Motor Iron-Core
Saturation Coefficient 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVOLV CLV
Set to the motor iron saturation coefficient at 50% of magnetic flux for motor
2. Automatically set during Auto-Tuning.
Default: 0.50
Min.: 0.00
Max.: 0.50
192
E4-08
(344)
Motor 2 Motor Iron-Core
Saturation Coefficient 2
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVOLV CLV
Set to the motor iron saturation coefficient at 75% of magnetic flux for motor
2. This value is automatically set during Auto-Tuning.
Default: 0.75
Min.: E4-07
Max.: 0.75
192
E4-09
(33F)
Motor 2 Mechanical Loss
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVOLV CLV
Sets the motor mechanical loss for motor 2 as a percentage of motor rated
power (kW).
Default: 0.0%
Min.: 0.0
Max.: 10.0
192
E4-10
(340)
Motor 2 Iron Loss
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG
Sets the motor iron loss.
Default:
<1>
Min.: 0 W
Max.: 65535 W
192
E4-11
(327)
Motor 2 Rated Power
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG OLV CLV
Sets the motor rated capacity in kW. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0.00 kW
Max.: 650.00 kW
193
<1> Default setting is dependent on parameters C6-01, Drive Duty Selection, and o2-04, Drive Model Selection.
<2> The number of decimal places in the parameter value depends on the drive model and the ND/HD selection in parameter C6-01. This value has two
decimal places (0.01 A) if the drive is set for a maximum applicable motor capacity up to and including 11 kW, and one decimal place (0.1 A) if
the maximum applicable motor capacity is higher than 11 kW.
B.7 E: Motor Parameters
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
405
B
Parameter List
