YASKAWA AC Drive-A1000 User Manual

B.17 V/f Pattern Default Values
The table below shows the V/f pattern settings default values depending on the control mode (A1-02) and the V/f pattern
selection (E1-03 in V/f Control).
Table B.5 E1-03 V/f Pattern Settings for Drive Capacity: CIMR-Ao5A0003 to CIMR-Ao5A0009
No. Unit V/f Control
OLV CLV
OLV/PM
AOLV/PM
CLV/PM
<99>
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E
F
<1>
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0 60.0 60.0
<2>
E1-05 V 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0
<2>
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0
<2>
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 0.0 –
E1-08 V 43.1 43.1 43.1 43.1 100.6 143.8 100.6 143.8 54.6 69.0 54.6 69.0 43.1 43.1 43.1 43.1 31.6 0.0 –
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5 0.5 0.0
<2>
E1-10 V 25.9 25.9 25.9 25.9 23.0 25.9 23.0 25.9 31.6 37.4 31.6 43.1 25.9 25.9 25.9 25.9 5.8 0.0 –
<1> This value determines the default values for E1-04 through E1-10 (E2-04 through E2-10 for motor 2).
<2> Default setting is dependent on parameter E5-01, Motor Code Selection.
<99>
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Table B.6 E1-03 V/f Pattern Settings for Drive Capacity: CIMR-Ao5A0011 to CIMR-Ao5A0032
No. Unit V/f Control
OLV CLV
OLV/PM
AOLV/PM
CLV/PM
<99>
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E
F
<1>
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0 60.0 60.0
<2>
E1-05 V 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0
<2>
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0
<2>
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 0.0 –
E1-08 V 40.3 40.3 40.3 40.3 100.6 143.8 100.6 143.8 51.8 66.1 51.8 66.1 40.3 40.3 40.3 40.3 31.6 0.0 –
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5 0.5 0.0
<2>
E1-10 V 20.1 20.1 20.1 20.1 17.3 20.1 17.3 20.1 25.9 31.6 25.9 37.4 20.1 20.1 20.1 20.1 5.8 0.0 –
<1> This value determines the default values for E1-04 through E1-10 (E2-04 through E2-10 for motor 2).
<2> Default setting is dependent on parameter E5-01, Motor Code Selection.
<99>
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
B.17 V/f Pattern Default Values
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
459
B
Parameter List
