YASKAWA AC Drive-A1000 User Manual

n
F4-07, F4-08: Terminal V1, V2 Signal Level
Sets the output signal level for terminals V1 and V2.
No. Parameter Name Setting Range Default
F4-07 Terminal V1 Signal Level 0, 1 0
F4-08 Terminal V2 Signal Level 0, 1 0
Setting 0: 0 to 10 V
Setting 1: -10 to 10 V
u
F5: Digital Output Card Settings
These parameters set the drive for operation with the digital output option card DO-A3. Refer to the instruction manual
packaged with the option card for specific details on installation, wiring, input signal level selection, and parameter setup.
n
F5-01 through F5-08: Digital Output Option Card Terminal Function Selection
When F5-09 = 2, the parameters listed in the table below assign functions to the output terminals on the option card.
No. Name Setting Range Default
F5-01 Terminal P1-PC Output Selection 0 to 192 2: Speed agree
F5-02 Terminal P2-PC Output Selection 0 to 192 4: Frequency detection 1
F5-03 Terminal P3-PC Output Selection 0 to 192 6: Drive ready
F5-04 Terminal P4-PC Output Selection 0 to 192 37: During frequency output
F5-05 Terminal P5-PC Output Selection 0 to 192 F: Not used
F5-06 Terminal P6-PC Output Selection 0 to 192 F: Not used
F5-07 Terminal M1-M2 Output Selection 0 to 192 0: During run
F5-08 Terminal M3-M4 Output Selection 0 to 192 1: Zero speed
n
F5-09: DO-A3 Output Mode Selection
Determines how the DO-A3 option card works with the drive.
No. Parameter Name Setting Range Default
F5-09 DO-A3 Output Mode Selection 0 to 2 0
Setting 0: Separate output functions for each of 8 terminals
Setting 1: Binary output
Setting 2: Output functions assigned by F5-01 through F5-08
u
F6: Communication Option Card
These parameters configure communication option cards and communication fault detection methods.
Some parameters apply to all communication option cards and some parameters apply to certain network options only. The
option cards are applicable to the parameter rows marked with an “O”.
Parameter
Communication Protocol
CC-Link MECHATROLINK-II PROFIBUS-DP CANopen DeviceNet
F6-01 to F6-03,
F6-06 to F6-08
O O O O O
F6-04, -10, -11, -14 O – – – –
F6-20 to F6-26 – O – – –
F6-30 to F6-32 – – O – –
F6-35 to F6-36 – – – O –
F6-50 to F6-63 – – – – O
5.6 F: Option Settings
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
201
5
Parameter Details
