H6-03: Pulse Train Input Gain
Sets the level of the input value selected in H6-01 when a pulse train signal with the frequency set in H6-02 is input to terminal
RP.
No. Name Setting Range Default
H6-03 Pulse Train Input Gain 0.0 to 1000.0% 100.0%
n
H6-04: Pulse Train Input Bias
Sets the level of the input value selected in H6-01 when no signal (0 Hz) is input to terminal RP.
No. Name Setting Range Default
H6-04 Pulse Train Input Bias -100.0 to 100.0% 0.0%
n
H6-05: Pulse Train Input Filter Time
Sets the pulse train input filter time constant in seconds.
No. Name Setting Range Default
H6-05 Pulse Train Input Filter Time 0.00 to 2.00 s 0.10 s
n
H6-06: Pulse Train Monitor Selection
Selects the monitor to output as a pulse train signal via terminal MP. Enter the three digits in Uo-oo to indicate which
monitor to output. Refer to U: Monitor Parameters on page 284 for a complete list of monitors. Monitors that can be selected
by H6-06 appear in the table below.
No. Name Setting Range Default
H6-06 Pulse Train Monitor Selection
000
<1>
, 031, 101, 102, 105,
116, 501, 502, 702 to 711,
801 to 809
102
<1> Set “000” when the terminal is not used or when using the terminal in the through mode.
n
H6-07: Pulse Train Monitor Scaling
Sets the output frequency at terminal MP when the specified monitor item is at 100%. Set H6-06 to 102 and H6-07 to 0 to
make the pulse train monitor output synchronous to the output frequency.
No. Name Setting Range Default
H6-07 Pulse Train Monitor Scaling 0 to 32000 Hz 1440 Hz
n
H6-08: Pulse Train Input Minimum Frequency
Sets the minimum output frequency detected by the pulse train input. Decreasing this setting reduces the time the drive needs
to react to changes in the input signal.
• The pulse input value becomes 0 when the pulse input frequency falls below this level.
• Enabled when H6-01 = 0, 1, or 2.
• When simple speed feedback in V/f Control is set as the function for terminal RP (H6-01 = 3), the minimum frequency
becomes the detection time for PG disconnect (F1-14).
No. Name Setting Range Default
H6-08 Pulse Train Input Minimum Frequency 0.1 to 1000.0 Hz 0.5 Hz
5.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
237
5
Parameter Details
