YASKAWA AC Drive-A1000 User Manual

Digital Operator Display Fault Name
oFA00
Option Card Connection Error at Option Port CN5-A
Option compatibility error
Cause Possible Solution
The option card installed into port CN5-A is
incompatible with the drive
Check if the drive supports the option card to be installed. Contact Yaskawa for assistance.
A PG option card is connected to option port
CN5-A
PG option boards are supported by option ports CN5-B and CN5-C only. Place the PG option card into
the correct option port.
Digital Operator Display Fault Name
oFA01
Option Card Fault at Option Port CN5-A
Option not properly connected
Cause Possible Solution
The option board connection to port CN5-A is
faulty
• Turn the power off and reconnect the option card.
• Check if the option card is properly plugged into the option port. Make sure the card is fixed properly.
• If the option is not a communication option card, try to use the card in another option port. If the option
card works properly in a different option port, replace the drive because port CN5-A is damaged. If the
error persists (oFb01 or oFC01 occur), replace the option board.
Digital Operator Display Fault Name
to
oFA03 to oFA06
Option card error occurred at option port CN5-A
,
oFA10, oFA11
to
oFA12 to oFA17
to
oFA30 to oFA43
Cause Possible Solution
Option card or hardware is damaged Replace the option card.
Digital Operator Display Fault Name
oFb00
Option Card Fault at Option Port CN5-B
Option compatibility error
Cause Possible Solution
The option card installed into port CN5-B is
incompatible with the drive
Make sure the drive supports the option card to be installed. Contact Yaskawa for assistance.
A communication option card has been
installed in option port CN5-B
Communication option cards are only supported by option port CN5-A. It is not possible to install more
than one comm. option.
Digital Operator Display Fault Name
oFb01
Option Card Fault at Option Port CN5-B
Option not properly connected
Cause Possible Solution
The option board connection to port CN5-B is
faulty
• Turn off the power and reconnect the option card.
• Check if the option card is properly plugged into the option port. Make sure the card is fixed properly.
• Try to use the card in another option port (in case of a PG option use port CN5-C). If the option cards
works in the other port, replace the drive because port CN5-B is damaged. If the error persists (oFA01
or oFC01 occur), replace the option board.
Digital Operator Display Fault Name
oFb02
Option Card Fault at Option Port CN5-B
Same type of option card already connected
Cause Possible Solution
An option card of the same type is already
installed in option port CN5-A
Except for PG options, each option card type can only be installed once. Make sure only one type of option
card is connected.
An input option card is already installed in
option port CN5-A
Install a comm. option, a digital input option, or an analog input option . The same type of card cannot
be installed twice.
Digital Operator Display Fault Name
to
oFb03 to oFb11
Option card error occurred at Option Port CN5-B
to
oFb12 to oFb17
to
oFb30 to oFb43
Cause Possible Solution
6.4 Fault Detection
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
307
6
Troubleshooting
