F1-09
(388)
Overspeed Detection Delay
Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the time in seconds for an overspeed situation to trigger a fault (oS).
Default:
<1>
Min.: 0.0 s
Max.: 2.0 s
196
F1-10
(389)
Excessive Speed Deviation
Detection Level
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the speed deviation detection level as a percentage of the maximum output
frequency.
Default: 10%
Min.: 0
Max.: 50
197
F1-11
(38A)
Excessive Speed Deviation
Detection Delay Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the time in seconds for a speed deviation situation to trigger a fault (dEv).
Default: 0.5 s
Min.: 0.0
Max.: 10.0
197
F1-12
(38B)
PG 1 Gear Teeth 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG).
A gear ratio of 1 will be used if F1-12 or F1-13 are set to 0.
Default: 0
Min.: 0
Max.: 1000
197
F1-13
(38C)
PG 1 Gear Teeth 2
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG). A gear ratio
of 1 will be used if F1-12 or F1-13 are set to 0.
Default: 0
Min.: 0
Max.: 1000
197
F1-14
(38D)
PG Open-Circuit Detection
Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
Sets the time required to trigger a PG Open fault (PGo).
Default: 2.0 s
Min.: 0.0
Max.: 10.0
196
F1-18
(3AD)
dv3 Detection Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
CLV/PM
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
CLV/PM
0: Disabled
n: Number of dv3 occurrences that must be detected to trigger a dv3 fault.
Default: 10
Min.: 0
Max.: 10
198
F1-19
(3AE)
dv4 Detection Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
CLV/PM
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
CLV/PM
0: Disabled
n: Number of pulses that the A and B pulse are reversed that triggers dv4
detection.
Default: 128
Min.: 0
Max.: 5000
198
F1-20
(3B4)
PG Option Card Disconnect
Detection 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
198
F1-21
(3BC)
PG 1 Signal Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
0: A pulse detection
1: AB pulse detection
Default: 0
Range: 0, 1
198
F1-30
(3AA)
PG Card Option Port for
Motor 2 Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
Sets the port for the PG option card used by motor 2.
0: CN5-C
1: CN5-B
Default: 1
Range: 0, 1
199
F1-31
(3B0)
PG 2 Pulses Per Revolution
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
Sets the number of pulses for a PG option card connected to port CN5-B.
Default: 1024 ppr
Min.: 0
Max.: 60000
196
F1-32
(3B1)
PG 2 Rotation Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
0: Pulse A leads
1: Pulse B leads
Default: 0
Range: 0, 1
197
F1-33
(3B2)
PG 2 Gear Teeth 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG).
A gear ratio of 1 will be used if F1-33 or F1-34 are set to 0.
Default: 0
Min.: 0
Max.: 1000
197
B.8 F: Options
