H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description Page
34 PID soft starter cancel
All Modes
Open: PID soft starter is enabled.
Closed: Disables the PID soft starter b5-17.
214
35 PID input level selection
All Modes
Closed: Inverts the PID input signal.
214
40
Forward run command
(2-Wire sequence)
All Modes
Open: Stop
Closed: Forward run
Note: Cannot be set together with settings 42 or 43.
214
41
Reverse run command
(2-Wire sequence)
All Modes
Open: Stop
Closed: Reverse run
Note: Cannot be set together with settings 42 or 43.
214
42
Run command
(2-wire sequence 2)
All Modes
Open: Stop
Closed: Run
Note: Cannot be set together with settings 40 or 41.
215
43
FWD/REV command
(2-Wire sequence 2)
All Modes
Open: Forward
Closed: Reverse
Note: Determines motor direction, but does not issue a Run command. Cannot be set
together with settings 40 or 41.
215
44 Offset frequency 1
All Modes
Closed: Adds d7-01 to the frequency reference.
215
45 Offset frequency 2
All Modes
Closed: Adds d7-02 to the frequency reference.
215
46 Offset frequency 3
All Modes
Closed: Adds d7-03 to the frequency reference.
215
47 Node setup
All Modes
Closed: Node setup for SI-S3 enabled.
215
60 DC Injection Braking command
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
Closed: Triggers DC Injection Braking.
215
61
External Speed Search
command 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM AOLV/PM
OLV
Closed: Activates Current Detection Speed Search from the maximum output frequency
(E1-04).
215
62
External Speed Search
command 2
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM AOLV/PM
OLV
Closed: Activates Current Detection Speed Search from the frequency reference.
215
63 Field weakening
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG
Closed: The drive performs Field Weakening control as set for d6-01 and d6-02.
215
65 KEB Ride-Thru 1 (N.C.)
All Modes
Open: KEB Ride-Thru 1 enabled.
215
66 KEB Ride-Thru 1 (N.O.)
All Modes
Closed: KEB Ride-Thru 1 enabled.
215
67 Communications test mode
All Modes
Tests the MEMOBUS/Modbus RS-485/422 interface. Displays “PASS” if the test completes
successfully.
215
B.9 H Parameters: Multi-Function Terminals
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
417
