YASKAWA AC Drive-A1000 - Page 449

No.
(Addr.
Hex)
Name Description
Analog Output
Level
Unit
U1-11
(4A)
Output Terminal Status
All Modes
Displays the output terminal status.
U1 - 11=
00000000
Multi-Function
Digital Output
(terminal M1-M2)
Digital Output
(terminal M3-M4)
Digital Output
(terminal M5-M6)
Multi-Function
Multi-Function
Not Used
Fault Relay
(terminal MA-MC closed
MA-MC open)
1
1
1
1
0
No signal output
available
–
U1-12
(4B)
Drive Status
All Modes
Verifies the drive operation status.
U1 - 12=
00000000
During run
During zero-speed
During REV
During fault reset
signal input
During speed agree
Drive ready
During alarm
detection
During fault detection
1
1
1
1
1
1
1
1
No signal output
available
–
U1-13
(4E)
Terminal A1 Input Level
All Modes
Displays the signal level to analog input terminal A1.
10 V: 100% 0.1%
U1-14
(4F)
Terminal A2 Input Level
All Modes
Displays the signal level to analog input terminal A2.
10 V: 100% 0.1%
U1-15
(50)
Terminal A3 Input Level
All Modes
Displays the signal level to analog input terminal A3.
10 V: 100% 0.1%
U1-16
(53)
Output Frequency after
Soft Starter
All Modes
Displays output frequency with ramp time and S-curves. Units determined
by o1-03.
10 V: Max frequency 0.01 Hz
U1-17
(58)
DI-A3 Input Status
All Modes
Displays the reference value input from the DI-A3 option card.
Display will appear in hexadecimal as determined by the digital card input
selection in F3-01.
3FFFF: Set (1 bit) + sign (1 bit) + 16 bit
No signal output
available
–
U1-18
(61)
oPE Fault Parameter
All Modes
Displays the parameter number that caused the oPEoo or Err (EEPROM
write error) error.
No signal output
available
–
U1-19
(66)
MEMOBUS/Modbus
Error Code
All Modes
Displays the contents of a MEMOBUS/Modbus error.
U1 - 19=
00000000
CRC Error
Data Length Error
Not Used
Parity Error
Overrun Error
Framing Error
Timed Out
Not Used
1
1
0
1
1
1
1
0
No signal output
available
–
B.15 U: Monitors
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
449
B
Parameter List
