Table B.3 A1-02 (Motor 1 Control Mode) Dependent Parameters and Default Values
No. Name Setting Range Resolution
Control Modes (A1-02)
OLV/PM (5)
<99>
AOLV/PM (6)
<99>
CLV/PM (7)
<99>
b2-01 DC Injection Braking Start Frequency 0.0 to 10.0 0.1 Hz 0.5 Hz
1.0%
<1>
0.5%
<1>
b2-04 DC Injection Braking Time at Stop 0.00 to 10.00 0.01 s 0.00 0.00 0.00
b3-01 Speed Search Selection at Start 0 to 1 – 0 0 1
b3-02 Speed Search Deactivation Current 0 to 200 1% – – –
b3-14 Bi-Directional Speed Search Selection 0 to 1 1 1 1 1
b8-01 Energy Saving Control Selection 0 to 1 – – 1 1
b8-02 Energy Saving Gain 0.0 to 10.0 0.1 – – –
b8-03 Energy Saving Control Filter Time Constant 0.00 to 10.00 0.01 s – – –
C2-01 S-Curve Time at Acceleration Start 0.00 to 10.00 0.01 s 1.00 1.00 1.00
C3-01 Slip Compensation Gain 0.0 to 2.5 0.1 – – –
C3-02 Slip Compensation Primary Delay Time 0 to 10000 1 ms – – –
C4-01 Torque Compensation Gain 0.00 to 2.50 0.01 0.00 0.00 0.00
C4-02 Torque Compensation Primary Delay Time 0 to 10000 1 ms 100 100 100
C5-01 ASR Proportional Gain 1 0.00 to 300.00 0.01 – – –
C5-02 ASR Integral Time 1 0.000 to 10.000 0.001 s – – –
C5-03 ASR Proportional Gain 2 0.00 to 300.00 0.01 – – –
C5-04 ASR Integral Time 2 0.000 to 10.000 0.001 s – – –
C5-06 ASR Primary Delay Time Constant 0.000 to 0.500 0.001 s – – –
C6-02 Carrier Frequency Selection 1 to F – 2 2 2
E1-04 Maximum Output Frequency 40.0 to 400.0 0.1 Hz
<2> <2> <2>
E1-05 Maximum Voltage 0.0 to 733.1 0.1 V
<2> <2> <2>
E1-06 Base Frequency 0.0 to 400.0 0.1 Hz
<2> <2> <2>
E1-07 Middle Output Frequency 0.0 to 400.0 0.1 Hz – – –
E1-08 Middle Output Frequency Voltage 0.0 to 733.1 0.1 V – – –
E1-09 Minimum Output Frequency 0.0 to 400.0 0.1 Hz – – –
E1-10 Minimum Output Frequency Voltage 0.0 to 733.1 0.1 V – – –
F1-01 PG 1 Pulses Per Revolution 0 to 60000 1 ppr 1024 1024 1024
F1-05 PG 1 Rotation Selection 0 to 1 – 1 1 1
F1-09 Overspeed Detection Delay Time 0.0 to 2.0 0.1 s – – –
L1-01 Motor Overload Protection Selection 0 to 4 – 4 4 4
L3-20 DC Bus Voltage Adjustment Gain 0.00 to 5.00 0.01 0.65 0.65 0.65
L3-21 Accel/Decel Rate Calculation Gain 0.00 to 10.00 0.01 2.50 2.50 2.50
L4-02 Speed Agreement Detection Width 0.0 to 20.0 0.1 Hz 2.0 Hz
4.0%
<1>
4.0%
<1>
L4-04 Speed Agreement Detection Width (+/-) 0.0 to 20.0 0.1 Hz 2.0 Hz
4.0%
<1>
4.0%
<1>
L8-38 Carrier Frequency Reduction Selection 0 to 2 1 0 0 0
L8-40
Carrier Frequency Reduction Off Delay
Time
0.00 to 2.00 0.01 s 0.00 0.00 0.00
o1-03 Digital Operator Display Selection 0 to 3 1 0 1 1
o1-04 V/f Pattern Display Unit 0 to 1 1 — 1 1
<1> Value calculated as a percentage of the maximum output frequency.
<2> Default setting is dependent on parameter E5-01, Motor Code Selection.
<99>
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
B.16 Control Mode Dependent Parameter Default Values
