No. Name Unit Default Settings
–
Model CIMR-Ao
– 5A0017 5A0022 5A0027 5A0032
C6-01 Drive Duty Selection –
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04 Drive Model Selection Hex. CAH CCH CDH CEH
E2-11 (E4-11) Motor Rated Power kW 7.5 11 11 15 15 18.5 18.5 22
b3-04 V/f Gain during Speed Search % 100 100 100 100 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-03
Energy Saving Control Filter Time
Constant
s 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 200 172 172 154 154 140 140 129
C5-17 (C5-37) Motor Inertia
kgm
2
0.037 0.053 0.053 0.076 0.076 0.138 0.138 0.165
C6-02 Carrier Frequency Selection – 1 7 1 7 1 7 1 7
E2-01 (E4-01) Motor Rated Current A 11 17 17 22 22 27 27 32
E2-02 (E4-02) Motor Rated Slip Hz 1.3 1.7 1.7 1.6 1.6 1.67 1.67 1.7
E2-03 (E4-03) Motor No-Load Current A 3.3 5.1 5.1 6.6 6.6 8.1 8.1 9.6
E2-05 (E4-05) Motor Line-to-Line Resistance Ω 1.45 1.17 1.17 0.9 0.9 0.66 0.66 0.52
E2-06 (E4-06) Motor Leakage Inductance % 15.5 19.6 19.6 17.2 17.2 20.1 20.1 23.5
E2-10 (E4-10) Motor Iron Loss for Torque Compensation W 263 385 385 440 440 508 508 586
L2-02 Momentary Power Loss Ride-Thru Time s 1 1 2 2 2 2 2 2
L2-03
Momentary Power Loss Minimum
Baseblock Time
s 1 1 1 1.2 1.2 1.2 1.2 1.2
L2-04
Momentary Power Loss Voltage Recovery
Time
s 0.8 0.9 0.9 1 1 1 1 1
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.18 0.27 0.27 0.24 0.24 0.32 0.32 0.36
L8-02 Overheat Alarm Level °C 120 120 120 120 115 115 115 115
L8-35 Installation Method Selection – 2 2 2 2 2 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10
n5-02 Motor Acceleration Time s 0.18 0.27 0.27 0.24 0.24 0.32 0.32 0.36
B.18 Defaults by Drive Model (o2-04) and ND/HD (C6-01)
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
461
B
Parameter List
