8 Monitor Displays (Un)
8-6
8.5 Monitoring Hall Sensor Signals (Un011)
With the Un011 monitor, the signal patterns of the hall sensor can be viewed.
Step
Display after Opera-
tion
Keys Operation
1 Press the MODE/SET Key to select the monitor display.
2 Press the UP or DOWN Key to select
Un011.
3
Press the DATA/SHIFT Key for
approximately one second
to display the hall sensor signal pattern.
4
Press the DATA/SHIFT Key for
approximately one second
to return to the display of step 2.
MODE
/
SET DATA
/
MODE
/
SET DATA
/
MODE
/
SET DATA
/
Phase-U
L
L
L
L
H
H
H
H
0
1
2
3
4
5
6
7
L
L
H
H
L
L
H
H
L
H
L
H
L
H
L
H
Phase-V Phase-W
Signal Monitor
Hall Sensor
Signal Pattern
Upper: ON at high level
Lower: OFF at low level
Phase-W signal monitor
Phase-V signal monitor
Phase-U signal monitor
MODE / SET DATA /

YASKAWA SGDV SERVOPACK Specifications

General

Model	SGDV
Type	SERVOPACK
Control Modes	Position, Speed, Torque
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Vibration Resistance	5.9 m/s² (0.6G) at 10-60Hz
Shock Resistance	49 m/s² (5G)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Regenerative overload, Encoder error
