5.1 Control Method Selection
5-3
5.1 Control Method Selection
The control method supported by the SGDV SERVOPACK are described below.
The control method can be selected with parameter Pn000.
Control Method Selection
Pn.000.1 Control Description
Reference
Section
n.0
[Factory setting]
Speed Control
Controls servomotor speed by means o
f an analog voltage speed
reference. Use in the following instances.
• To control speed
• For position control using the encoder
pulse output from the
SERVOPACK to form a position loop in the host controller.
5.3 Speed
Control
n.1 Position Control
Controls the position of the machine by means of a pulse train
position reference.
Controls the position with the number of input pulses, and con-
trols the speed with the input pulse f
requency. Use when posi-
tioning is required.
5.4 Position
Control
n.2 Force Control
Controls the servomotor’s output force by means of
an analog
voltage force reference. Use to output the required amount of
force for operations such as stopping on contact.
5.5 Force
Control
n.3
Internal Set Speed Con-
trol
Uses the three input signals /P-CON
(/SPD-D), /P-CL (/SPD-A),
and /N-CL (/SPD-B) to control the speed as set in advance in the
SERVOPACK. Three operating speeds can be set in the SER-
VOPACK
.
When selecting this control, an analog reference is not necessary.
5.6 Internal
Set Speed
Control
n.4
Internal Set Speed Con-
trol Speed
Control
These are switching modes for using
the four control methods
given above in combination.
Select the control switching method that best
suits the applica-
tion.
5.7 Combina-
tion of Control
Methods
n.5
Internal Set Speed Con-
trol Position Control
n.6
Internal Set Speed Con-
trol Force Control
n.7
Position Control
Speed Control
n.8
Position Control
Force Control
n.9
Force Control Spee
d
Control
n.A
Speed Control Spe
ed
Control with Zero
Clamp Function
The zero clamp function can b
e used in speed control.
5.3.5 Zero
Clamp Func-
tion
n.B
Position Control
Position C
ontrol with
Reference Pulse Inhibit
Function
The reference pulse inhibit function
can be used in position con-
trol.
5.4.8 Refer-
ence Pulse
Inhibit Func-
tion
To Next Page
