Notation Used in this Manual
• Notation for Reverse Signals
The names of reverse signals (i.e., ones
that are valid when low) are written with a forward slash (/) before the
signal name.
Notation Example
BK = /BK
• Notation for Parameters
The notation depends on whether the parameter requires a
value setting (parameter for numeric settings) or
requires the selection of a function (parameter for selecting functions).
• Parameters for Numeric Settings
Notation Example
Pn406
Emergency Stop Force
Setting Range
0% to 800% 1% 800 After change
Setting Unit Factory Setting When Enabled
Classification
Setup
Parameter Meaning When Enabled Classification
Pn002
After restart
n.0
[Factory setting]
n.1
Uses the absolute linear scale as
an incremental linear scale.
Uses the absolute linear scale as
an absolute linear scale.
Setup
Parameter
number
Parameter
number
Position
Force
Control methods for which the parameter applies.
Speed
: Speed control
: Position control
: Force control
Indicates the
parameter setting
before shipment.
Indicates when a
change to the
parameter will be
effective.
Indicates the
parameter
classification.
Indicates the
minimum setting unit
for the parameter.
Force
Position Speed
Indicates the setting
range for the parameter.
The notation “n.” indicates a parameter
for selecting functions. Each corresponds to
the setting value of that digit. The notation shown
here means that the third digit is 1.
This section explains the
selections for the function.
• Parameters for Selecting Functions
Linear
1st digit
2nd digit
3rd digit
4th digit
Panel Operator Display
(Display Example for Pn002)
Digit Notation Setting Notation
Meaning Notation Meaning
Pn002.0
Pn002.1
Pn002.2
Pn002.3
Indicates the value for the
1st digit of parameter Pn002.
Indicates the value for the
2nd digit of parameter Pn002.
Indicates the value for the
3rd digit of parameter Pn002.
Indicates the value for the
4th digit of parameter Pn002.
Pn002.0 = x
or n.x
Pn002.1 = x
or n.x
Indicates that the value for the
1st digit of parameter Pn002 is x.
Indicates that the value for the
2nd digit of parameter Pn002 is x.
Pn002.2 = x
or n.x
Pn002.3 = x
or n.x
Indicates that the value for the
3rd digit of parameter Pn002 is x.
Indicates that the value for the
4th digit of parameter Pn002 is x.
