3 Wiring and Connection
3.1.6 General Precautions for Wiring
3-16
3.1.6 General Precautions for Wiring
To ensure safe, stable application of the servo system, observe the following precautions when wiring.
Use the connection cables specified in
the
-V Series Product Catalog (No.: KAEP S800000 42). Design
and arrange the system so that each cable will be as short as possible.
Use shielded twisted-pair cables or screened unshielded
twisted-pair cables for I/O signal cables and linear
scale connection cables.
Make sure that the length of each cable is equal to or shorter
than the maximum wiring length listed here.
I/O signal cables: 3 m
Connection cables for linear servomotor main circuit: 20 m
Connection cables for serial converter unit: 20 m
Connection cables for linear scale: 15
m
Connection cables for hall sensor: 15 m
Control power supply cables for the SERVOPACK with a 400-V power supply (+24 V, 0 V):10 m
Observe the following precautions when
wiring the ground.
Use a cable as thick as possible (at least 2.0 mm
2
).
Grounding to a resistance of 100
or less for 100-V, 200-V SERVOPACKs, 10 or less for 400-V SER-
VOPACKs is recommended.
Be sure to ground at only one point.
Ground the servomotor directly if the servomotor is insulated from the machine.
The signal cable conductors are as thin as 0.2 mm
2
or 0.3 mm
2
. Do not impose excessive bending force or
tension.
• Use a molded-case circuit breaker (1QF) or fuse to protect the main circuit.
The SERVOPACK connects directly to a commercial
power supply; it is not isolated
through a transformer or other device.
Always use a molded-case circuit breaker (1QF)
or fuse to protect the servo system
from accidents involving different power system voltages or other accidents.
• Install a ground fault detector.
The SERVOPACK does not have a built-in protective circuit for grounding.
To configure a safer system, install a grou
nd fault detector against overloads and
short-circuiting, or install a ground fault detector combined with a molded-case circuit
breaker.
• Do not turn the power ON and OFF more than necessary.
• Do not use the SERVOPACK for applications
that require the power to turn ON and
OFF frequently. Such applications will cause elements in the SERVOPACK to dete-
riorate.
• As a guideline, at least one hour should be allowed between the power being
turne
d ON and OFF once actual operation has been started.
