9 Troubleshooting
9.1.1 List of Alarms
9-4
A.b10
Speed Reference A/D
Error
The A/D converter for speed reference input
is faulty
.
Gr.2 Available
H H
H
A.b11
Speed Reference A/D
Dat
a Error
A/D conversion data of speed reference
input is incorrect.
Gr.2
Available
A.b20
Reference Force Input
Read Error
The A/D converter for force reference input
is faulty.
Gr.2 Available
A.b31 Current Detection Error 1
The current detection circuit for phase U is
faulty
.
Gr.1
N/A
A.b32 Current Detection Error 2
The current detection circuit for phase V is
faulty
.
Gr.1
N/A
A.b33 Current Detection Error 3
The detection circuit for the
current is
faulty.
Gr.1
N/A
A.bF0 System Alarm 0
"Internal program error 0" of the SERVO-
PACK occurred.
Gr.1 N/A
A.bF1 System Alarm 1
"Internal program error 1" of the SERVO-
PACK occurred.
Gr.1 N/A
A.bF2 System Alarm 2
"Internal program error 2" of the SERVO-
PACK occurred.
Gr.1
N/A
A.bF3 System Alarm 3
"Internal program error 3" of the SERVO-
PACK occurred.
Gr.1 N/A
A.bF4 System Alarm 4
"Internal program error 4" of the SERVO-
PACK occurred.
Gr.1 N/A
A.C10 Servo Overrun Detected The servomotor ran out of control. Gr.1 Available
L H
L
A.C20 Phase Detection Error The detection of the phase is incorrect. Gr.1 N/A
A.C21 Hall Sensor Error The hall sensor is faulty. Gr.1 N/A
A.C22
Phase Information
Disagreement
The phase information does not match. Gr.1
N/A
A.C50 Polarity Detection Error The polarity detection failed. Gr.1 N/A
A.C51
Overtravel Detection at
Polarity Detect
ion
The overtravel signal was detected at polar-
ity detection.
Gr.1
Available
A.C52
Polarity Detection
Uncompleted
The servomotor was turned ON under the
condition of
polarity detection uncom-
pleted.
Gr.1
Available
A.C53
Out of Range for Polarity
De
tection
The moving distance exceeded the set value
of Pn48E during polarity detection.
Gr.1
N/A
A.C54 Polarity Detection Error 2 The polarity detection failed. Gr.1 N/A
A.C80
Absolute Encoder Clear
Error
The data for the absolute linear scale was
not properly cleared or set.
Gr.1 N/A
A.C90
Encoder Communications
Error
Communications between the SERVO-
PACK and the linear scale is
not possible.
Gr.1
N/A
A.C91
Encoder Communications
Position Data Error
A linear scale position data calculation error
occurred.
Gr.1 N/A
A.C92
Encoder Communications
Timer Error
An error occurs in the communications
tim
er between the linear scale and the SER-
VOPACK.
Gr.1
N/A
A.CA0 Encoder Parameter Error Linear scale parameters are faulty. Gr.1 N/A
A.Cb0 Encoder Echoback Error
Contents of communications with linear
scale are incorrect.
Gr.1 N/A
(cont’d)
Alarm
Number
Alarm Name Meaning
Servo-
motor
Stopping
Method
Alarm
Reset
Alarm Code Output
ALO1 ALO2 ALO3
To Next Page
