7.12 Write Prohibited Setting (Fn010)
7-19
7
Utility Functions (Fn)
7.12 Write Prohibited Setting (Fn010)
This function prevents changing parameters by mistake and sets restrictions on the execution of the utility
function.
Parameter changes and execution of the utility function become restricted in the following manner when W
rite
prohibited (P.0001) is assigned to the write prohibited setting parameter (Fn010).
Parameters: Cannot be changed. If you attempt to ch
ange it, "NO-OP" will flash on the display and the
screen will return to the main menu.
Utility Function: Some functions cannot be executed. (Refer to the following table.) If you attempt to exe-
cute these utility functions, "NO-OP" will flash on the disp
lay and the screen will return to the main menu.
Parameter
No.
Function
Write Prohibited
Setting
Reference
Section
Fn000 Alarm history display Executable 7.2
Fn002 JOG operation Cannot be executed 7.3
Fn003 Origin search Cannot be executed 7.4
Fn004 Program JOG operation Cannot be executed 7.5
Fn005 Initializing parameter settings Cannot be executed 7.6
Fn006 Clearing alarm history Cannot be executed 7.7
Fn009 Automatic tuning of analog (speed, force)
reference offset Cannot be executed
5.3.2
5.5.2
Fn00A Manual servo tuning of speed reference offset Cannot be executed 5.3.2
Fn00B Manual servo tuning of force reference offset Cannot be executed 5.5.2
Fn00C Offset adjustment of analog monitor output Cannot be executed 7.8
Fn00D Gain adjustment of analog monitor output Cannot be executed 7.9
Fn00E
Automatic offset-signal adjustment of the motor current detection
signal
Cannot be executed 7.10
Fn00F
Manual offset-signal adjustment of the
motor current detection
signal
Cannot be executed 7.11
Fn010 Write prohibited setting 7.12
Fn011 Servomotor model display Executable 7.13
Fn012 Software version display Executable 7.14
Fn014 Resetting configuration error in optio
n modules Cannot be executed 7.15
Fn01B Vibration detection le
vel initialization Cannot be executed 7.16
Fn01E Display of SERVOPACK and servomotor ID Executable 7.17
Fn020 Origin setting Cannot be executed 7.18
Fn030 Software reset Executable 7.19
Fn080 Polarity Detection Cannot be executed 7.20
Fn200 Tuning-less levels setting Cannot be executed 6.2.2
Fn201 Advanced autotuning Cannot be executed 6.3.2
Fn202 Advanced autotuning by reference Cannot be executed 6.4.2
Fn203 One-parameter tuning Cannot be executed 6.5.2
Fn204 Anti-resonance control adjustment function Cannot be executed 6.6.2
Fn205 Vibration suppression function Cannot be executed 6.7.2
Fn206 EasyFFT Cannot be executed 7.21
Fn207 Online vibration monitor Cannot be executed 7.22
