5.8 Limiting Force
5-69
5
Operation
5.8.5 Checking Output Force Limiting during Operation
The following signal can be output to indicate that the servomotor output force is being limited.
Note: Use parameter Pn50F.0 to allocate the /CLT signal for use. For details, refer to 3.3.2 Output Signal Allocations.
Type Signal Name
Connector
Pin Number
Setting Meaning
Output /CLT Must be allocated
ON (closed)
Servomotor output force is being lim-
ited.
OFF (open)
Servomotor output force is
not being
limited.

YASKAWA SGDV SERVOPACK Specifications

General

Model	SGDV
Type	SERVOPACK
Control Modes	Position, Speed, Torque
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Vibration Resistance	5.9 m/s² (0.6G) at 10-60Hz
Shock Resistance	49 m/s² (5G)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Regenerative overload, Encoder error
