xiv
Harmonized Standards
 North American Safety Standards (UL)
 European Directives
Model
UL Standards
(UL File No.)
SERVOPACK SGDV UL508C (E147823)
Model European Directives Harmonized Standards
SERVOPACK SGDV
Machinery Directive
2006/42/EC
EN ISO13849-1: 2008
EN 954-1
EMC Directive
2004/108/EC
EN 55011 /A2 group 1, class A
EN 61000-6-2
EN 61800-3
Low Voltage Directive
2006/95/EC
EN 50178
EN 61800-5-1

YASKAWA SGDV SERVOPACK Specifications

General

Model	SGDV
Type	SERVOPACK
Control Modes	Position, Speed, Torque
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Vibration Resistance	5.9 m/s² (0.6G) at 10-60Hz
Shock Resistance	49 m/s² (5G)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Regenerative overload, Encoder error
