6.7 Vibration Suppression Function (Fn205)
6-51
6.7 Vibration Suppression Function (Fn205)
The vibration suppression function is described in this section.
6.7.1 Vibration Suppression Function
The vibration suppression function suppresses transitional vibration at frequency as low as 1 to 100 Hz that is
generated mainly when positioning if the machine stand vibrates.
This function is set automatically when advanced autotuning
or advanced autotuning by reference is executed.
In most cases, this function is not necessary. Use this function only if fine-tuning is required or readjustment is
required as a result of a failure to detect vibration.
Perform one-parameter tuning (Fn203) if required to improve th
e response characteristics after performing
this function.
(1) Preparation
Check the following settings before performing the vibration suppression function.
The message “NO-OP” indicating that the settings are not appr
opriate will be displayed, if all of the following
conditions are not met.
• The control must be set to position control.
• The tuning-less function must be disabled (Pn170.0 = 0).
• The test without a motor function must be disabled (Pn00C.0 = 0).
• The write prohibited setting parameter (Fn010)
must be set to Write permitted (P.0000).
(2) Items Influencing Performance
If continuous vibration occurs when the servomotor is not moving, the vibration suppression function cannot
be used to suppress the vibration effectively. If the result is not satisfactory, perform anti-resonance control
adjustment function (Fn204) or one-parameter tuning (Fn203).
(3) Detection of Vibration Frequencies
No frequency detection may be possible if the vibration does not appear as a position error or the vibration
resulting from the position error is too small.
The detection sensitivity can be adjusted by changing the setting for the remained vibration detection width
(Pn5
60) which is set as a percentage of the positioning completed width (Pn522). Perform the detection of
vibration frequencies again after adjusting the remained vibration detection width (Pn560).
CAUTION
• If this function is executed, related parameters will be set automatically. Therefore, there will be a large
response change after this function is enabled or disabled. Enable the function in a state where the
machine can come to an emergency stop at any time to ensure the safety operation of the machine.
• Be sure to set a suitable value for the
mass ratio (Pn103) using advanced autotuning before executing the
vibration suppression function. If the setting greatly differs from the actual mass ratio, normal control of the
SERVOPACK may not be possible, and vibration may result.
• This function detects vibration frequency betwe
en 1 to 100 Hz. Vibration will not be
detected for frequencies outside of this range, and instead, "F-----" will be displayed.
• Frequency detection will not be performed if no vibration results from position error or
the vibration frequencies are outside the range of detectable frequencies. If so, use a
device, such as a displacement sensor or vibration sensor, to measure the vibration
frequency.
• If vibration frequencies automatically detected are no
t suppressed, the actual fre-
quency and the detected frequency may differ. Fine-tune the detected frequency if
necessary
.
