7 Utility Functions (Fn)
7-26
7.17 Display of SERVOPACK and Servomotor ID (Fn01E)
This function displays ID information for SERVOPACK, servomotor, linear scale, and option module con-
nected to the SERVOPACK. The ID information of some option modules is not stored in the SERVOPACK.
"N
ot available" will be displayed for these option modules.
This function cannot be executed from the panel operator on the SERVOPACK.
To use this function, the digital operator (JU
SP-OP05A-1-E) or SigmaWin+ is needed.
Refer to
 -V Series User's Manual, Operation of Digital Operator (No.: SIEP S800000 55) for the operating
procedure of the digital operator.
The following items can be displayed.
 If the option module is not connected, "Not connect" will be displayed after the module name.
(1) Preparation
There are no tasks that must be performed before the execution.
ID Items to be Displayed
SERVOPACK ID
• SERVOPACK model
• SERVOPACK serial number
• SERVOPACK manufacturing date
• SERVOPACK input voltage (V)
• Maximum applicable motor capacity (W)
• Maximum applicable motor rated current (Arms)
Servomotor ID
• Servomotor model
• Servomotor order number
• Servomotor manufacturing date
• Servomotor input voltage (V)
• Servomotor capacity (W)
• Servomotor rated current (Arms)
Encoder ID
• Linear scale model
• Linear scale serial number
• Linear scale manufacturing date
• Linear scale type/resolution
Safety Option Module
ID
*
• Safety Option Module model
• Safety Option Module serial number
• Safety Option Module manufacturing date
• Safety Option Module ID number
Feedback Option Mod-
ule ID
*
• Feedback Option Module model
• Feedback Option Module serial number (Reserved area)
• Feedback Option Module manufacturing date
• Feedback Option Module ID
