Setting 2: Open Loop Vector
• For general, variable-speed applications.
• For applications requiring precise speed control, quick response, and higher torque at low speeds.
Setting 5: PM Open Loop Vector
For operating SPM, IPM, and various permanent magnet motors. Takes advantage of Energy Saving features when
operating with derated torque.
n
A1-03: Initialize Parameters
Resets parameter settings back to their
original default values. After the initialization the parameter automatically returns
to 0.
No. Parameter Name Setting Range Default
A1-03 Initialize Parameters 0, 1110, 2220, 3330, 5550 0
Setting 0: No Initialization
Setting 1110: User Initialize
The modified drive parameters are returned to the
values selected as user settings. User settings are stored when parameter
o2-03 = “1: Set Defaults”.
Note: A “user-initialization” resets all parameters to a user-defined set of default values that were previously saved to the drive. To clear the
user-defined default values, set parameter o2-03 to “2”.
Setting 2220: 2-Wire Initialization
Resets all parameters back to their original default settings with digital inputs S1 and S2 configured as forward run and
reverse run, respectively. A 2-wire sequence assigns functions to input terminals S1 and S2.
Refer to Setting 40/41: Forward Run/Reverse Run Command for 2-Wire Sequence on page 183 for more information.
Setting 3330: 3-Wire Initialization
The drive parameters are returned to factory default values with digital inputs S1, S2, and S5 configured as run, stop, and
forward/reverse respectively. A 3-wire sequence assigns functions to input terminals S1, S2, and S5.
Refer to Setting 0: 3-Wire Sequence on page 177 for more information.
Setting 5550: oPE04 Reset
If parameters on a certain drive have been edited and then a different terminal block is installed with different settings
saved in its built-in memory, an oPE04 error will appear on the display. To use the parameter settings saved to the terminal
block memory, set A1-02 to “5550”.
Notes on Parameter Initialization
The parameters shown in Table 5.1 will not be reset when the drive is initialized by setting A1-03 = 2220 or 3330. The
fault history will not be reset when the drive is initialized by A1-03 = 2220 or 3330. Although the control mode in A1-02
is not reset when A1-03 is set to 2220 or 3330, it may change when an application preset is selected.
Table 5.1 Parameters not Changed by Drive Initialization
No. Parameter Name
A1-00 Language Selection
A1-02 Control Method Selection
A1-07 DriveWorksEZ Function Selection
E1-03 V/f Pattern Selection
E5-01 Motor Code Selection (for PM motors)
E5-02 Motor Rated Capacity (for PM motors)
E5-03 Motor Rated Current (for PM motors)
E5-04 Motor Poles (for PM motors)
E5-05 Motor Stator Resistance (for PM motors)
E5-06 Motor d Axis Inductance (for PM motors)
E5-07 Motor q Axis Inductance (for PM motors)
E5-09 Motor Induction Voltage Constant 1 (for PM motors)
E5-24 Motor Induction Voltage Constant 2 (for PM motors)
o2-04 Drive/kVA Selection
L8-35 Installation Selection
5.1 A: Initialization
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
113
5
Parameter Details
