YASKAWA V1000 Technical Manual

Table D.8 Wire Gauge and Torque Specifications
Drive
Model
Terminal
For Japan and Asia
<1>
For United States
<2>
For Europe and China
<3>
Screw
Size
Tightening
Torque
N•m (lb.in.)
Recomm.
Gauge
mm
2
Wire Range
mm
2
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Recomm.
Gauge
mm
2
Wire Range
mm
2
4A0001
4A0002
4A0004
R/L1, S/L2,
T/L3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2,
W/T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
⊖, ⊕1, ⊕2
2 2 to 5.5 – 14 to 10 – 2.5 to 6
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
4A0005
4A0007
4A0009
R/L1, S/L2,
T/L3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/
T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
⊖, ⊕1, ⊕2
2 2 to 5.5 – 14 to 10 – 2.5 to 6
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
2 2 to 5.5 10 14 to 10 2.5 2.5 to 6
4A0011
R/L1, S/L2,
T/L3
2 2 to 5.5 12 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2,
W/T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
⊖, ⊕1, ⊕2
2 2 to 5.5 – 14 to 10 – 2.5 to 6
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
2 2 to 5.5 10 14 to 10 2.5 2.5 to 6
4A0018
R/L1, S/L2,
T/L3
3.5 2 to 14 10 14 to 6 2.5 2.5 to 16
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2,
W/T3
3.5 2 to 14 10 14 to 6 2.5 2.5 to 16
⊖, ⊕1, ⊕2
3.5 2 to 14 – 14 to 6 – 2.5 to 16
B1, B2 2 2 to 5.5 – 14 to 10 – 4 to 6
5.5 2 to 14 8 14 to 6 2.5 2.5 to 16 M5
2 to 2.5
(17.7 to 22.1)
4A0023
R/L1, S/L2,
T/L3
5.5 3.5 to 14 10 10 to 6 4 4 to 16
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2,
W/T3
5.5 3.5 to 14 10 10 to 6 4 4 to 16
⊖, ⊕1, ⊕2
5.5 3.5 to 14 – 10 to 6 – 4 to 16
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
5.5 5.5 to 14 8 10 to 6 4 4 to 16 M5
2 to 2.5
(17.7 to 22.1)
4A0031
R/L1, S/L2,
T/L3
14 5.5 to 14 8 10 to 6 6 6 to 16
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2,
W/T3
8 5.5 to 14 8 10 to 6 6 6 to 16
⊖, ⊕1, ⊕2
14 5.5 to 14 – 10 to 6 – 6 to 16
B1, B2 3.5 2 to 8 – 10 to 8 – 6 to 10
2.7 to 3.0
(23.9 to 26.6)
8
<4>
5.5 to 14
6
<4>
10 to 6
6
<4>
6 to 16 M6
5.4 to 6.0
(47.8 to 53.1)
4A0038
R/L1, S/L2,
T/L3
14 5.5 to 14 6 10 to 6 10 6 to 16
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2,
W/T3
14 5.5 to 14 8 10 to 6 6 6 to 16
⊖, ⊕1, ⊕2
14 5.5 to 14 – 10 to 6 – 6 to 16
B1, B2 5.5 3.5 to 8 – 10 to 8 – 6 to 10
2.7 to 3.0
(23.9 to 26.6)
14 5.5 to 14 6 10 to 6 10 6 to 16 M6
5.4 to 6.0
(47.8 to 53.1)
<1> Gauges listed here are for use in Japan and Asia.
<2> Gauges listed here are for use in the United States.
D.3 UL Standards
444
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
