<5. Functions>
130
IM 01E21A02-03EN
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 28 Threshold level 4 Adhesion Level4
Speciesthevaluetojudge
level 4.
DTB 29 Result►Status Adhesion Status
Displays the electrode
adhesion detection level.
DTB 30 Check cycle Adhesion Check Cycle
Speciesthedataupdate
cycle for electrode adhesion
detection.
*1: From the table below, select the use of the electrode adhesion detection function.
Selection
Description
Display
F
OUNDATION
Fieldbus
Disable Disable Does not use the electrode adhesion detecting function.
Enable Enable Uses the electrode adhesion detecting function.
NOTE
If the electrode adhesion detecting function is not used, the electrode resistance value and level
are cleared.
NOTE
Before using the electrode adhesion detecting function, be sure to make sure that the sensor is in
the full pipe state. If the sensor is in the empty pipe state, the function to detect adhesion may not
run normally.
NOTE
Theelectrodeadhesiondetectingfunctionisrestrictedbytheconductivityofuid.The
recommended conductivities are as follows.
Meter size Conductivity
2.5 to 10 mm 30μS/cmorlarger
15to400mm(0.5to16in.) 10μS/cmorlarger
500 mm 20μS/cmorlarger
NOTE
If the data update cycle for the adhesion detection is shortened, the error of the electrode
resistancevalueincreases.Donotchangethedefaultvalueunlessespeciallyspecied.
