<6. Parameter Lists>
175
IM 01E21A02-03EN
Relative
Index
Index Parameter Name Default Value
Write
Mode
Description
80 1080
FD_EXTENDED_
MAP_6
0x00000000 AUTO
Parameter set by the user as the mask
from FD_EXTENDED_ACTIVE_6 to
DEVICE CONDITION_ACTIVE_6. For
details about bit assignment, refer to FD
and bit items in the table in Subsection
5.6.2.
81 1081
FD_EXTENDED_
MAP_7
0x00000000 AUTO
Parameter set by the user as the mask
from FD_EXTENDED_ACTIVE_7 to
DEVICE CONDITION_ACTIVE_7. For
details about bit assignment, refer to FD
and bit items in the table in Subsection
5.6.2.
82 1082
FD_EXTENDED_
MAP_8
0x00000000 AUTO
Parameter set by the user as the mask
from FD_EXTENDED_ACTIVE_8 to
DEVICE CONDITION_ACTIVE_8. For
details about bit assignment, refer to FD
and bit items in the table in Subsection
5.6.2.
83 1083
DEVICE_
CONDITION_
ACTIVE_1
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_1 for FD_
EXTENDED_ACTIVE_1. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
84 1084
DEVICE_
CONDITION_
ACTIVE_2
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_2 for FD_
EXTENDED_ACTIVE_2. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
85 1085
DEVICE_
CONDITION_
ACTIVE_3
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_3 for FD_
EXTENDED_ACTIVE_3. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
86 1086
DEVICE_
CONDITION_
ACTIVE_4
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_4 for FD_
EXTENDED_ACTIVE_4. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
87 1087
DEVICE_
CONDITION_
ACTIVE_5
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_5 for FD_
EXTENDED_ACTIVE_5. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
88 1088
DEVICE_
CONDITION_
ACTIVE_6
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_6 for FD_
EXTENDED_ACTIVE_6. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
89 1089
DEVICE_
CONDITION_
ACTIVE_7
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_7 for FD_
EXTENDED_ACTIVE_7. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
90 1090
DEVICE_
CONDITION_
ACTIVE_8
0x00000000 -
Showsresultsreectingthemaskby
FD_EXTENDED_MAP_8 for FD_
EXTENDED_ACTIVE_8. For details
about bit assignment, refer to FD and bit
items in the table in Subsection 5.6.2.
91 1091 SOFTWARE_REV - - Software revision
92 1092
WRITE_LOCK_
LEVEL
2 AUTO See 5.12.
