  <4.Conguration>
42
IM 01E21A02-03EN
Table 4.16 View Object for AI Function Block
Relative
Index
Parameter Name
View
1 2 3 4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 PV 5 5
8 OUT 5 5
9 SIMULATE
10 XD_SCALE 11
11 OUT_SCALE 11
12 GRANT_DENY 2
13 IO_OPTS 2
14 STATUS_OPTS 2
15 CHANNEL 2
16 L_TYPE 1
17 LOW_CUT 4
18 PV_FTIME 4
19 FIELD_VAL 5 5
20 UPDATE_EVT
21 BLOCK_ALM
22 ALARM_SUM 8 8
23 ACK_OPTION 2
24 ALARM_HYS 4
25 HI_HI_PRI 1
26 HI_HI_LIM 4
27 HI_PRI 1
28 HI_LIM 4
29 LO_PRI 1
30 LO_LIM 4
31 LO_LO_PRI 1
32 LO_LO_LIM 4
33 HI_HI_ALM
34 HI_ALM
35 LO_ALM
36 LO_LO_ALM
37 BLOCK_ERR_DESC_1
Total 31 26 31 46
Table 4.17 View Object for DI Function Block
Relative
Index
Parameter Name
View
1 2 3 4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 PV_D 2 2
8 OUT_D 2 2
9 SIMULATE_D
10 XD_STATE 2
11 OUT_STATE 2
12 GRANT_DENY 2
13 IO_OPTS 2
14 STATUS_OPTS 2
15 CHANNEL 2
16 PV_FTIME 4
17 FIELD_VAL_D 2 2
18 UPDATE_EVT
19 BLOCK_ALM
20
ALARM_SUM|ALARM_
SUM_DI
8 8
21 ACK_OPTION 2
22 DISC_PRI 1
23 DISC_LIM 1
24 DISC_ALM
Total 22 8 22 19
