<5. Functions>
96
IM 01E21A02-03EN
NE
107
Error Message
Error Description Countermeasure FD bit
Display
F
OUNDATION
Fieldbus
C 361:DiagTB O/S Mode
Diagnostic TB in
O/S Mode
The DTB block is in the
O/S mode.
Change the DTB block
mode.
7 14
C 362:MaintTB O/SMode
Maintenance TB in
O/S Mode
The MTB block is in the
O/S mode.
Change the MTB block
mode.
7 13
C 363:DispTB O/S Mode
Display TB in O/S
Mode
The LTB block is in the
O/S mode.
Change the LTB block
mode.
7 12
 Warning
The device works normally and measurement is also normal but warning occurs.
NE
107
Error Message
Error Description Countermeasure FD bit
Display
F
OUNDATION
Fieldbus
S 082:Pls 1 saturate
Pulse output 1
saturated
Saturation of pulse
output 1 was detected.
Check process value
and pulse output 1
parameter settings.
3 5
C 085:Cable miscon Cable misconnect
Misconnection of cable
was detected.
Check the signal cable
and excitation cable
connection.
3 2
C 086:Coil insulation
Coil insulation
warning
Insulation deterioration
of the coil was
detected.
Contact Yokogawa
service center.
3 1
M 087:Adhesion lv 3
Adhesion over level
3
The resistance value
of the electrodes
exceeded Level 3.
(Adhesiondetection
of insulation to the
electrode)
Recommend cleaning
the electrode.
4 31
N 088:LC warn
Low conductivity
warning
Decrease of
conductivity was
detected.
Checkuid
conductivity.
4 30
M 089:Insu detect Insulation detection
Insulation deterioration
of electrode was
detected.
Contact Yokogawa
service center.
4 29
N 090:FLN over lv 3
Flow noise over
level 3
Flow noise exceeded
Level 3.
(Detectionofow
noise)
Checkiftheuidhasa
problem(conductivity
andbubble).
4 28
N 091:FLN over lv 4
Flow noise over
level 4
Flow noise exceeded
Level 4.
(Detectionofow
noise)
Checkiftheuidhasa
problem(conductivity
andbubble).
4 27
C 092:AZ warn Autozero warning
Result of zero
adjustment exceeded
10 cm/s.
Checkuidisstopped
when executing zero
adjustment.
4 26
C 093:Verif warn Vericationwarning
Interruption of
vericationfunction
was detected.
ExecutetheVerication
function again.
4 25
C 094:Fact noise warn
Factory noise
warning
Theuctuationofow
became larger.
Checktheuid. 4 24
C 095:Simulate active Simulation active
The test mode for any
oftheowvelocity,
volumetricowrate,
massowrate,calorie,
pulse output, status
input, or status output
was executed.
Release simulation or
test mode.
4 23
S 098:Pls1x Pulseoutput1xed
It was detected that
pulseoutput1isxed.
Check whether pulse
output 1 is in the test
mode or not.
4 20
