YOKOGAWA MW100 User Manual

3-58
IM MW100-01E
Alarm Summary Display
The most recent alarms are displayed in a separate window. Select the number of alarms
to be displayed from 30, 60, 100, and 150. The display is automatically updated once per
minute. You can also update the display manually by clicking Update.
Alarm Time
Click to sort in ascending or descending order.
Type
Shows the alarm level and type.
1-H
Alarm type(H/L/rH/rL/dH/dL/tH/tL)
Alarm level(1 to 4)
Channel
Shows the channel on which the alarm occurred.
Click to sort in ascending or descending order.
Number of Displayed Alarms
Sets the number of alarms to display.
3.15 Measured Data Monitor Display/Settings
