5-10
IM MW100-01E
5.2 Main Module Specifications
Recording interval: Set the recording interval for each measurement group as a
multiple of the measurement interval.
For a measurement interval of 50 ms, 500 ms, or 5 s, set a
multiple of 1, 2, 4, or 10.
For other measurement intervals, set a multiple of 1, 2, 5, or 10.
Otherwise, set a multiple of 1, 2, 5, or 10.
File name: Automatically generated using the data and serial number
MDDIXXXX.MXD
M: Month fi le created (local time), 1-9, X (October),
Y (November), Z (December)
DD: Date when fi le created (local time), 1-31
I: Files in measurement groups 1 to 3 are 1 to 3
Computed data fi le is M
Thinned values, T
XXXX: Sequence number 0000-9999
MXD: MW100 fi le extension (uppercase)
Data length: Measurement groups for which TRIGGER was selected can be
set individually.
For the measurement groups on which Direct mode was selected,
all groups have the same length.
Trigger Type Selectable data length Target
Direct 30 min. All groups
1, 2, 3, 4, 6, 8, or 12 hours
1, 2, 3, 5, 7, 10, 14, or 31 days
Trigger 10, 20, or 30 min. Individual groups
1, 2, 3, 4, 6, 8, or 12 hours
1, 2, 3, 5, 7, or 10 days
File size: Within approximately 10 Mbyte per fi le
File size calculation: File size (bytes) = header size* + data size **
* Header size (bytes) = 904 + no. of recording channels × 232
** Measurement data size (bytes) = no. of recording measurement
channels × 4 × no. of samples
Math data size (bytes) = no. of recording math channels × 6 × no. of
samples
No. of samples = Data length (s)/recording interval (s)
Ex.) Recording interval: 100 ms; no. of measurement channels, 24; data
length, 10 min.:
Header size = 904 (bytes) + 24 × 232 (bytes) = 6472 (bytes)
Data size = 24 (bytes) × (600 (s)/0.1 (s)) = 576,000 (bytes)
File size = 6472 + 576000 = 582472
≈ 56.8 Kbyte
Guideline of the sample time for the different CF card sizes (when one type of recording
interval is used):
128MB
Number of
Saved CHs
Recording
Interval
512MB
1GB
Capacity of the CF card
10 CHs
24 CHs
60 CHs
8.8 hours
3.7 days
18.5 days
37 days
74 days
36.8 hours
7.7 days
15.3 days
30 days
14.8 hours
3.0 days
6.1 days
12.3 days
31 days
10 ms
100 ms
500 ms
1 s
2 s
100 ms
500 ms
1 s
2 s
100 ms
500 ms
1 s
2 s
5 s
35.3 hours
14.8 days
74 days
148 days
296 days
6.1 days
30 days
61 days
122 days
2.4 days
12.3 days
24.6 days
49 days
123 days
2.8 days
28.9 days
144 days
289 days
578 days
12.0 days
60 days
119 days
239 days
4.8 days
24.1 days
48 days
96 days
241 days
