Spectral Profiles Modem Profiles Management Model
Table 25: Configuring Mode Specific PSD Profiles
Choose from the available Profile AIDs.
Assign the profile an identifiable Description (i.e. ADSL2 Plus...)
Do one of the following: either upload values from an existing file and modify
them according to the following step, or define each parameter as described in
the next steps.
Copy values from an
existing profile:
Under Copy from Profile (bottom of the pane), choose from the list of
predefined profiles.
Click Get. The parameters will be updated.
Modify the required parameters to customize them to your needs.
Click OK. The new profile will be added to the Mode Specific Profile pane.
Define the mode
specific ADSL2/Plus
parameters:
Under Transmission Mode, select ADSL2/Plus. The relevant fields will be
available.
Define the (Upstream) US PSD Mask In Use by choosing the relevant Annex
options.
Define the mode
specific VDSL2
parameters:
Under Transmission Mode, select VDSL2. The relevant fields will be
available.
Select the regional band-plan annex and the relevant PSD parameters. The annex
specifies the PSD Mask for numerous regional bandplans and are designed to
provide coexistence with other services:
Annex A/B:
Annex A- specifies band-plans for the North American region and enables
VDSL2 to be deployed with traditional POTS telephony or in an all-digital mode
(similar to Annex J in ADSL2).
Annex B - specifies band-plans for Europe and enables VDSL2 deployment with
POTS, ISDN or all digital compliant PSD.
Select the PSD Shape and if US0, first band, is used (US0 PSD Mask in Use),
select the PSD for that band.
Select the profile according to your regional deployment architecture (e.g.
country, CO unit location)
Define the
Aggregated Power
Limits:
Define the relevant Maximum Nominal Aggregated Tx and Rx power limits.
