Ethernet Service Configuration EVC Services Definition
3. Select from the list of the available Service IDs. Up to 8 service IDs are supported
(SERV-1 to SERV-8). Only the available service IDs are displayed (i.e. defined services
are removed from the list).
4. In the Description field, assign the service a meaningful name.
5. Select from the list of predefined BW Profiles. Only defined BW profiles are displayed.
If the required BW profile is not available, define it via the BW Profile option and it will
be available for the service.
6. Select the Queue ID.
7. In the Shaper field, configure whether to apply shaper (Yes) or not (No) to the service as
the frames egress.
The Shaper is used to limit data transmit rate and remove data bursts. The shaper is
available per queue, and when "Service per Queue" is configured, the shaper becomes a
Service Shaper.
Service Shaper rate limit is calculated automatically as the sum of CIR + EIR (specified
in the BW profile(s) (on page 10-7) used by the Service(s) as Ingress Meter). For a
Service with an enabled Shaper, it is recommended to use a BW profile which doesn't
limit the CBS/EBS (should be set to unlimited), otherwise the shaper may work
improperly.
Notes:
Shaper cannot be enabled for a Service, if the CIR and/or EIR specified in the BW
profile(s) used by that Service(s) are unlimited.
Shaper cannot be enabled for a Service, if the total sum of CIR+EIR specified for that
service(s) is greater than theoretically possible on the HSL port of the ML700 model.
8. Click OK. The new profile will be added to the Bandwidth Profiles list.
NOTE: The defined service may be modified or deleted by selecting it and clicking the corresponding
buttons at the bottom of the pane.
