Equipment and Port Configuration High Speed Link (HSL)
4. Select the Template AID. This is a predefined template comprising of a number of
predefined profiles displayed in the corresponding tabs. The tabs are the same for all
templates; however, the parameter values of each tab correspond to the template.
5. Check the “Apply Low BW Thresholds for Multi-mode calibration” in case that there are
Low BW thresholds and system is set to Multi-mode (on page 6-14)
6. To review profile details, choose the specific profile that is required for the HSL
calibration by clicking its tab: for example, a Rate Profile, Line Spectrum or VDSL2 PSD
Profile (note that three profiles of this type are available).
The tab will be highlighted and displayed (Rate Profile in the example above).
NOTE: If any parameter requires updating, update the specific profile first (see Modem
Profiles Management Model (on page 6-1)) and only then update the template (if
required).
7. Click OK.
