Description and Basic Operation of the SDA-5500 and 5510: Global Configuration
225
13
CAUTION ! Executing this function will cause all saved
files, functions, and memory to be lost.
Display Test: This option allows you to test the operation of the display.
With this option highlighted, press the Enter key and follow the instructions
displayed.
Transmitter Diagnostics: With Transmitter Diagnostics highlighted, press
the Enter key to access the following features:
• Transmitter On/Off: When the transmitter is turned on, this option
provides a CW RF signal that can be used as a troubleshooting or
installation aid.
• Transmitter Attenuator: Use the up and down diamond keys to enter
the amount of attenuation for the CW attenuated signal.
• Transmitter Frequency: Enter the frequency for the transmitted signal.
CAUTION ! Subscriber interference could result if the
frequency is set to a local carrier frequency.
• Sweep Telemetry On/Off: When this is turned on, the unit will modulate
the CW signal similar to the telemetry signal.
PathTrak Demo On/Off: This setting allows you to activate or deactivate a
demo of the PathTrak feature.
Measurements Setup
To enter the MEASUREMENTS setup menu (Fig. 13-6), select
MEASUREMENTS from the main SETUP menu. You will see options for
adjusting eight variables.
