Appendix B
Specifications
Frequency
Range: 5 to 1,000 MHz
Accuracy: ±10 ppm at 25°C; ± 10 ppm drift over temp.;
± 3 ppm/year aging
Resolution bandwidths: 30, 280 kHz and 2MHz (30 kHz for CTB/CSO
only)
Tuning resolutions: 10 kHz
Sweep resolution: 250 kHz maximum
Level Measurement
Range: -40 to +60 dBmV
Resolution: 0.1 dB
Accuracy: ±1.0 dB from -20 to +50°C
Log linearity: ±0.5 dB
Flatness: ±0.5 dB
Signal types: CW, single carrier, video (single or dual
audio/NICAM), audio, digital
